Enter/Exit Programming Mode

Product Reference Guide 121

ISBT 128 Concatenation Mode

Specifies the concatenation mode between Static and Dynamic.

DEFAULT

$CI8CM00CR)

ISBT 128 Concatenation Mode = Static

$CI8CM01CR)

ISBT 128 Concatenation Mode = Dynamic

This option is only valid when ISBT 128 Concatenation is enabled (see "

ISBT 128 Concate-

nation" on page 120

).
