To Next Page

To Previous Page

Enter/Exit Programming Mode

Product Reference Guide 185

Maxicode

Maxicode Enable / Disable

Enables/disables ability of reader to decode Maxicode labels.

DEFAULT

$CMXEN00(CR)

Maxicode = Disable

$CMXEN01(CR)

Maxicode = Enable

Maxicode Primary Message Transmission

Enables/disables the transmission of only the Primary Message when the Secondary Message is not readable.

DEFAULT

$CMXPT00(CR)

Maxicode Primary Message Transmission = Disable

$CMXPT01(CR)

Maxicode Primary Message Transmission = Enable
