Product Reference Guide 237
Appendix A
Technical Specifications
Tabl e 45 contains Physical and Performance Characteristics, User Environment and Regulatory
information.
Table 45. Technical Specifications
.
Item Description
QD24XX
Physical Characteristics
Color Black & White
Dimensions
Height 6.4"/163 mm
L
ength 3.6"/91 mm
Width 1.6"/41 mm
Weight (without cable) Approximately 5.1 ounces/145 g
Electrical Characteristics
Voltage & Current
Input Voltage: 4.5 - 14.0VDC
Operating (typical): 140mA
Operating (max): 380mA
Idle/standby (typical): 50mA
Performance Characteristics
Light Source LEDs
Roll (Tilt) Tolerance Up to ± 360°
Pitch Tolerance ± 65°
Skew (Yaw) Tolerance ± 60°
Field of View 40° Hx26° V
Print Contrast Minimum 25% minimum reflectance
