References
228 QuickScan™ I QD24XX
Scanning Features
Scan Mode
This mode is associated with typical handheld reader operation. Selects the scan operating mode for the reader. The
following selections are valid for all models:
Trigger Single:
When the trigger is pulled, scanning is activated until one of the following occurs:
- Scanning Active Time has elapsed
- a label has been read
- the trigger is released
Trigger Hold Multiple:
When the trigger is pulled, scanning starts and the product scans until the trigger is released
or Scanning Active Time has elapsed. Reading a label does not disable scanning. Double Read Timeout prevents
undesired multiple reads of the same label while in this mode.
Trigger Pulse Multiple:
When the trigger is pulled, continuous scanning is activated until Scanning Active Time
has elapsed or the trigger has been released
and pulled again. Double Read Timeout prevents undesired multiple
reads of the same label while in this mode.
Flashing:
The reader flashes on and off regardless of the trigger status. Flash rate is controlled by Flash On Time
and Flash Off Time. When Flash is ON the imager reads continuously; when Flash is OFF
scanning is deactivated.
Always On:
No trigger pull is required to read a bar code. Scanning is continually on. If the trigger is pulled, the
reader acts as if it is in Trigger Single Mode. Double Read Timeout prevents undesired multiple reads of the same
label while in this mode.
Stand Mode:
No trigger pull is required to read a bar code. Scanning is turned on automatically when an item is
placed in the reader’s field of view. If the trigger is pulled, the reader acts as if it in single read mode. Double Read
Timeout prevents undesired multiple reads while in this mode.
