Datalogic QuickScan QBT2400 User Manual

Enter/Exit Programming Mode Batch Features
218 QuickScan™ I QD24XX/QBT24XX/QM24XX
Copy Configuration to Base Station
Scan the following label to copy the current scanner configuration to the Base Station. Use this
method when the Auto Configuration Update feature is disabled and you want a one-time con-
figuration update to be performe
d on the Base Station.
Copy Configuration to Base Station
Cpycfg2Ba
Do not scan an ENTER/EXIT PROGRAMMING MODE label with this bar code.
BATCH FEATURES
Batch Mode
This option specifies whether to store labels in the handheld while disconnected from the base.
Options are as follows:
• Disabled — The handheld will not store/batch labels.
• Automatic — The handheld will store labels to RAM when the handheld goes out of range
an
d is disconnected from the remote device.
• Manual — The handheld will always store labels t
o Flash memory. The user must manually
send the stored labels to the remote device using a special "batch send" label.
DEFAULT
$CBTBM00(CR)
Batch Mode = Disabled
$CBTBM01(CR)
Batch Mode = Automatic
$CBTBM02(CR)
Batch Mode = Manual

Datalogic QuickScan QBT2400 Specifications

General

Connectivity	Bluetooth
Battery Type	Lithium-Ion
Battery Capacity	1400 mAh
IP Rating	IP42
Print Contrast Ratio (Minimum)	25%
Interfaces Supported	USB, RS-232, Keyboard Wedge
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-40 to 70 °C / -40 to 158 °F
Drop Resistance	Withstands drops from 1.5 m / 5.0 ft
Radio Range (Open Air)	100 m
Type	Handheld
Scan Rate	60 frames per second
Resolution	0.1 mm
Humidity	5 to 95% non-condensing
Light Source	Red LED
Supported Barcodes	1D / 2D and postal codes
