Technical Specifications
274 QuickScan™ I QD24XX/QBT24XX/QM24XX
Base Station Indications (Cordless Models ONLY)
INDICATION LEDS
Power-up Complete Yellow LED on
Reader Disabled by the HOST or the communication
with H
OST is not established
Yellow LED blinking ~1Hz
Data/labels are transmitted to the HOST Yellow LEDs turned off for 100mSec
Programming Mode Yellow LED blinks quickly
Configuration alignment with the handheld is in prog-
ress
Red LED blinks quickly
Battery charging in progress Red LED on
Battery charging complete Green LED on
Battery charger error
Green LED and Red LEDs blink alternatively
~1Hz
No handheld
is placed on th
e cradle Red and Green LEDs off
Base Station Button Indicators
BUTTON PUSH
EVENT
CORDLESS
RED
INDICATOR(**)
GREEN
INDICATOR(**)
Push at power-up
force device connection
(A
laddin)
Off
Slow blink
Fast blink
< 5 sec Paging Off Fast blink
> 5 sec Unlink Off Slow blink
To push the button, insert a paper clip in the hole at the label in the bottom of the Base.

Datalogic QuickScan QBT2400 Specifications

General

Connectivity	Bluetooth
Battery Type	Lithium-Ion
Battery Capacity	1400 mAh
IP Rating	IP42
Print Contrast Ratio (Minimum)	25%
Interfaces Supported	USB, RS-232, Keyboard Wedge
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-40 to 70 °C / -40 to 158 °F
Drop Resistance	Withstands drops from 1.5 m / 5.0 ft
Radio Range (Open Air)	100 m
Type	Handheld
Scan Rate	60 frames per second
Resolution	0.1 mm
Humidity	5 to 95% non-condensing
Light Source	Red LED
Supported Barcodes	1D / 2D and postal codes
