Datalogic QuickScan QBT2400 User Manual

Bluetooth-Only Features Enter/Exit Programming Mode
Product Reference Guide 221
BLUETOOTH-ONLY FEATURES
The features following in this section are valid only for QuickScan Bluetooth models. Also refer-
ence the Setup section for instructions on Linking a BT Reader to a PC, starting on page 16.
RF ADDRESS STAMPING
These features allow configuration of source radio data inclusion.
Source Radio Address Transmission
Enables/disables the ability of source radio address information to be transmitted to the host
and, if so, at what position with respect to the label data. See page 262 in “References” for
detailed information and examples for setting this feature.
DEFAULT
$CBTAS00(CR)
Source Radio Address Transmission = Do Not Include
$CBTAS01(CR)
Source Radio Address Transmission = Prefix
When included as a prefix, the source-radio ID is displayed after all label formatting
has been applied. The 6 byte hex address is sent as 12 ascii characters, i.e., an address
of 00 06 66 00 1A ED will be sent as (shown in hex): 30 30 30 36 36 36 30 30 31 41 45 44

Datalogic QuickScan QBT2400 Specifications

General

Connectivity	Bluetooth
Battery Type	Lithium-Ion
Battery Capacity	1400 mAh
IP Rating	IP42
Print Contrast Ratio (Minimum)	25%
Interfaces Supported	USB, RS-232, Keyboard Wedge
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-40 to 70 °C / -40 to 158 °F
Drop Resistance	Withstands drops from 1.5 m / 5.0 ft
Radio Range (Open Air)	100 m
Type	Handheld
Scan Rate	60 frames per second
Resolution	0.1 mm
Humidity	5 to 95% non-condensing
Light Source	Red LED
Supported Barcodes	1D / 2D and postal codes
