Datalogic QuickScan QBT2400 User Manual

Item Description
Performance Characteristics
Light Source LEDs
Roll (Tilt) Tolerance Up to ± 360°
Pitch Tolerance ± 65°
Skew (Yaw) Tolerance ± 60°
Field of View 40° Hx26° V
Print Contrast Minimum 25% minimum reflectance
Depth of Field (Typical)
a
a. 13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade A, typical environmental
light, 20°C, label inclination 10°
Symbology
Code 39
5mil: 0.2" - 5.9" (0.5 - 15cm)
10mil: 0" - 8.7" (0 - 22cm)
20mil: up to 16" (40cm)
EAN
7.5mil: 0" - 5.9" (0 - 15cm)
13mil: 0.2" - 13.8" (0.5 - 35cm)
PDF 417
6.6mil: 0.39" - 5.1" (1.0 - 130cm)
10mil: 0" - 8.3" (0 - 21cm)
15mil: 0.2" - 9.5" (0.5 - 24cm)
Data Matrix
10mil: 0.39" - 5.1" (1.0 - 13 cm)
15mil: 0" - 7.1" (0 - 18cm)
QR Code
10mil: 0.2" - 5.1" (0.5 - 13cm)
15mil: 0" - 7.1" (0 - 18cm)
Minimum Element Width
Standard Range:
1D Minimum Resolution = 4 mil
PDF-417 Minimum Resolution = 5 mil
Data Matrix Minimum Resolution = 7.5 mil
Technical Specifications
266 QuickScan™ I QD24XX/QBT24XX/QM24XX

Datalogic QuickScan QBT2400 Specifications

General

Connectivity	Bluetooth
Battery Type	Lithium-Ion
Battery Capacity	1400 mAh
IP Rating	IP42
Print Contrast Ratio (Minimum)	25%
Interfaces Supported	USB, RS-232, Keyboard Wedge
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-40 to 70 °C / -40 to 158 °F
Drop Resistance	Withstands drops from 1.5 m / 5.0 ft
Radio Range (Open Air)	100 m
Type	Handheld
Scan Rate	60 frames per second
Resolution	0.1 mm
Humidity	5 to 95% non-condensing
Light Source	Red LED
Supported Barcodes	1D / 2D and postal codes
