TC1200 REFERENCE MANUAL
24
3
CODE SELECTION
Description Parameter Value
Code 39
Code 39 Disable C3EN 00
Enable 01
Code 39 Full ASCII Disable C3FA 00
Enable 01
Code Length Control Variable C3LC 00
Fixed 01
Set Length Length 1 (or Min Length) from 1 to 50 characters C3L1 q
Length 2 (or Max Length) 0 or from 1 to 50 characters C3L2 q
Code 32 (Italian Pharma) Disable P3EN 00
Enable 01
Code 32 Check Tx Disable P3CT 00
Enable 01
Code 32 Start/Stop Tx Disable P3SS 00
Enable 01
Check Options
Check Calculation Disable C3CC 00
Enable Standard Check 01
Enable Mod-7 Check 02
Enable Italian Post Check 04
Enable Daimler Chrysler Check 08
Code 39 Check Tx Disable C3CT 00
Enable 01
Code 39 Start/Stop Tx Disable C3SS 00
Enable 01
Decoding Options
Minimum Reads One Read C3MR 01
Two Reads 02
Three Reads 03
Four Reads 04
Decoding Level Disable C3DL 00
Level 1 01
Level 2 02
Level 3 03
Level 4 04
Level 5 05
Interdigit Ratio Any ratio or 1 to 10 C3IR r
Character Correlation Disable C3CO 00
Enable 01
Quiet Zones Quiet Zone on One Side C3LO 01
Quiet Zones on Two Sides 02
Auto 03
Virtual Quiet Zones on Two Sides 04
Small Quiet Zones on Two Sides 05
Stitching Disable C3ST 00
Enable 01
q = Hex value from 00 to 32 representing the decimal number
r = Hex value from
00 to 0A representing the decimal number of the interdigit space/module ratio (00 = any ratio)
