Figure 22: Estimated RX level versus actual RX level
-105
-100
-95
-90
-85
-80
-75
-70
-65
-105 -100 -95 -90 -85 -80 -75 -70 -65
Estimated
RX LEVEL
(dBm)
Actual RX LEVEL (dBm)
Estimated RX LEVEL (16MHz PRF Free Space)
Estimated RX LEVEL (64MHz PRF Free Space)
Estimated RX LEVEL (64MHz PRF Multipath)
Actual RX LEVEL
