1 Introduction
1.1 About the DW1000
The DW1000 is a fully integrated low power, single chip CMOS radio transceiver IC compliant with the
IEEE 802.15.4-2011 ultra-wideband (UWB) standard.
• It facilitates proximity detection to an accuracy of +/- 10 cm using two-way ranging time-of-flight (TOF)
measurements.
• It facilitates real time location of assets in to an accuracy of +/- 10 cm using either two-way ranging (TOF)
measurements or one-way time difference of arrival (TDOA) Time Difference of Arrival schemes
• It spans 6 RF bands from 3.5 GHz to 6.5 GHz
• It supports data rates of 110 kbps, 850 kbps and 6.8 Mbps
• Its high data rates allow it to keep on-air time short and thereby save power and extend battery lifetimes
• Its ability to deal with severe multipath environments makes it ideal for highly reflective RF
environments
1.2 About this document
This user manual describes the operation and programming of the DW1000 and discusses some of the
design choices to be considered when implementing systems using it.
Information already contained in the DW1000 data sheet is not reproduced here and it is intended that the
reader should use this user manual in conjunction with the DW1000 data sheet.
The document is divided into a number of sections each of which deals with a particular aspect of the
DW1000 as follows: -
Section
No
Section Name
Information covered
2
Overview of the DW1000
Gives an overview of the DW1000, describes how to interface
to the device and details its various operating modes
3
Message Transmission
Describes the functionality and use of the DW1000 transmitter
4
Message Reception
Describes the functionality and use of the DW1000 receiver
5
Media Access Control (MAC)
hardware features
Describes the MAC level functionality provided in hardware by
the DW1000.
6
Other features of the DW1000
Describes other features supported by the DW1000
7
The DW1000 register set
Describes DW1000 user-accessible register set in detail, lists all
user accessible bit fields in each register and their respective
functions.
8
DW1000 Calibration
Describes the parameters of the DW1000 that require
calibration; the methodology that should be used in calibrating
them and how often they require calibration.
