6.3.1 OTP memory map
The OTP memory locations are as defined in Table 10. The OTP memory locations are each 32-bits wide, OTP
addresses are word addresses so each increment of address specifies a different 32-bit word.
Table 10: OTP memory map
OTP
Address
Size
(Used
Bytes)
Byte [3]
Byte [2]
Byte [1]
Byte [0]
Programmed
By
0x000
4
64 bit EUID
(These 64 bits get automatically copied over to Register File 0x01:EUI on each reset.)
Customer
0x001
4
0x002
4
Alternative 64bit EUID
Customer
0x003
4
0x004
4
40 bit LDOTUNE_CAL
(These 40 bits can be automatically copied over to Sub Register File 0x28:30 LDOTUNE
on wakeup)
Decawave Test
0x005
1
0x006
4
{“0001,0000,0000“, "CHIP ID (20 bits)"}
Decawave Test
0x007
4
{“0001”“, "LOT ID (28 bits)"}
DecawaveTest
0x008
2
-
-
V
meas
@ 3.7 V
V
meas
@ 3.3 V
DecawaveTest
0x009
1 / 1
-
-
T
meas
@ Ant Cal
T
meas
@ 23 °C
Customer / Deca-
wave Test
0x00A
0
-
Reserved
0x00B
4
-
Reserved
0x00C
2
-
Reserved
0x00D
4
-
Reserved
0x00E
4
-
Reserved
0x00F
4
-
Reserved
0x010
4
CH1 TX Power Level PRF 16
Customer
0x011
4
CH1 TX Power Level PRF 64
Customer
0x012
4
CH2 TX Power Level PRF 16
Customer
0x013
4
CH2 TX Power Level PRF 64
Customer
0x014
4
CH3 TX Power Level PRF 16
Customer
0x015
4
CH3 TX Power Level PRF 64
Customer
0x016
4
CH4 TX Power Level PRF 16
Customer
0x017
4
CH4 TX Power Level PRF 64
Customer
0x018
4
CH5 TX Power Level PRF 16
Customer
0x019
4
CH5 TX Power Level PRF 64
Customer
0x01A
4
CH7 TX Power Level PRF 16
Customer
0x01B
4
CH7 TX Power Level PRF 64
Customer
0x01C
4
TX/RX Antenna Delay – PRF 64
TX/RX Antenna Delay – PRF 16
Customer
0x01D
0
-
-
-
-
Customer
0x01E
2
-
-
OTP Revision
XTAL_Trim[4:0]
Customer
0x01F
0
-
-
-
-
Customer
:
:
:
:
:
:
Reserved
0x400
4
SR Register (see below)
Customer
