4. Specifications <for customer and installation personnel>
Power supply voltage 10V ～ 16V DC(For 12V vehicle）
+B line 2A（IGN ON）
1mA（IGN OFF）
ILM line 5mA
Operation temperature range -20 ～ +60℃ , -4 ～ +140°F（Under 80％ relative humidity）
Storage temperature range -30 ～ +80℃ , -22 ～ +176°F（Under 80％ relative humidity）
Applicable speed pulse 2/4/8/16pulse (mainly for Japanese vehicles)
Pulse free setting: 1,274 ～ 16,562pulse/km,
2,051 ～ 26,665pulse/mile（corresponds to 2 ～ 26pulse)
Applicable number of cylinders 1･2･3･4･5･6･8（4cycle）
Dimensions Refer to part names and dimensions section.
Current consumption of ADVANCE
Control unit
(Maximum value obtained when connecting 7 gauges and displays)
4.1. Display items
Display range Format
0 ～ 399km/h（0 ～ 239MPH) numeral
0 ～ 11,000rpm numeral/bar
OP1
Turbo/Boost/
Intake manifold press.
-100 ～ 300kPa (-29.5inHg ～ 45.0PSI) numeral/bar
OP2 Oil Press. 0 ～ 1,000kPa（0 ～ 145PSI) numeral
OP3 Fuel Press. 0 ～ 600kPa（0 ～ 87PSI) numeral
OP4 Oil Temp. 0 ～ 150℃（32 ～ 302°F) numeral
OP5 Water Temp. 0 ～ 150℃（32 ～ 302°F) numeral
OP6 Exhaust temp. 0 ～ 1,100℃（32 ～ 2,012°F) numeral
0 ～ 1,000kPa（0 ～ 145PSI) numeral
10 ～ 16V numeral
0 ～ 999,999km (0 ～ 599,999mile) numeral
0.0 ～ 9999.9km (0.0 ～ 9999.9mile) numeral
00:00 ～ 99:99 numeral
OP means optional parts. To display OP1 through OP6, optional sensor sets need to be
purchased separately. If ADVANCE gauges (sensors) are already installed, the sensor set is not
necessary additionally. (e.g. Oil pressure sensor and the ADVANCE oil pressure sensor wire are
already installed, oil pressure can be displayed without purchasing OP2 sensor set.)
A turbo sensor for 300kPa (45PSI) is required to correctly display the boost pressure over
200kPa (29PSI).
Turbo and fuel pressure sensor inputs are required to display the differential pressure.
The odometer accumulates up to the upper limit of the display range, but at that point the
display is locked and the addition stops.
