9.7.2. Real time mode
After the opening mode is done, the display switches to the real time mode. During real
time mode, vehicle information is displayed in real time.
9.7.2.1. Gauge mode
The real time mode has four different gauge modes (layouts), 1 through 4. Display items
can be changed in all zones.
■Change the gauge mode
FD OPR
The gauge modes can be changed each time 【F1 button】 is pressed.
Gauge1 Gauge 2
Gauge 3 Gauge 4
If the sensor of the displayed item is not connected, "x" is displayed in the zone.
⇒9.5 Switching of display items and size
