Defi ADVANCE FD User Manual

ADVANCE FD Manual 43 Return to top
9.4.3. TURBO BAR maximum scale value setting [TURBO BAR MAX
SCALE]
The maximum scale value of the turbo/manifold pressure bar can be set.
Setting items On the screen Setting options Default
TURBO BAR maximum scale
value setting
(When the unit kPa is set)
TURBO BAR MAX SCALE 300 / 200 / 120 / 20 200kPa
TURBO BAR maximum scale
value setting
(When the unit PSI is set)
TURBO BAR MAX SCALE 45 / 30 / 15 / 3 30PSI
Use 【F2 button】 to move the selection frame to [TURBO BAR MAX SCALE]。
Press the 【F1 button】 to select the TURBO BAR maximum pressure value.
The [300] must be used in combination with the turbo sensor dedicated for 300 kPa. If it
is used in combination with other turbo sensors, the correct value will not be displayed.
300kPa 200kPa
120kPa 20kPa
