9.6. Opening/Ending mode
When the ignition is turned on, the FD performs the opening mode. When the ignition is
turned off, the FD performs the ending mode. And then the power supplies to the Control
Unit and FD are shut off.
Depending on vehicles, the ignition is not turned off immediately after the key is turned
off. In the case, the ending mode doesn’t start until the ignition is turned off.
■Change of Opening/Ending mode
The opening and ending modes can be selected from A and B types by sliding the dip
switch 2 on the ADVANCE Control Unit. If gauges are connected the ADVANCE System, the
opening/ending modes for gauges are also changed.
Both types consist of digital displays and lighting of sequential indicators. Try both types!
Change the mode when the ignition is off.
