ADVANCE FD Manual 65 Return to top
9.7.6. Record peak mode
This mode displays the maximum values from the time that recording was started during
the record mode. For oil pressure and fuel pressure, the maximum and minimum values are
displayed in sequence. Even when differential pressure is displayed, the peak fuel pressure
value is displayed in the fuel pressure zone. During the record peak mode, [●REC PEAK] is
displayed in the multi-display zone.
CU OPR (Slide switch position：【UPPER】)
■If neither oil pressure sensor nor fuel pressure sensor is connected
1. Press the 【MIDDLE button】 during the record mode to shift to the record peak mode.
2. Press the 【MIDDLE button】 again to return to the record mode. After 3 minutes from
the start of recording, it will return to the real time mode.
■If either oil pressure sensor or fuel pressure sensor is connected
1. Press the 【MIDDLE button】 during the record mode to shift to the record peak mode
(high peak) and the maximum values are displayed.
2. Press the 【MIDDLE button】 during the high peak display to shift to the record peak
mode (low peak). The minimum values are displayed for oil pressure and fuel pressure, and
the maximum values are displayed for other items.
3. Press the 【MIDDLE button】 again to return to the record mode. When the 【LEFT
button】 is pressed or 3 minutes have elapsed since the start of recording, the display
returns to the real time mode.
