ADVANCE FD Manual 74 Return to top
9.10. Sequential indicator
8 red LEDs light up according to engine speed, and all LEDs flash when the engine speed
exceeds the warning set point. The lighting pattern can be selected from [SINGLE] and
[DUAL].
The lighting pattern, step, and ON/OFF is set in the display setup mode.
⇒9.4.4 Sequential indicator lighting pattern setting [SEQ. IND. PATTERN]
⇒9.4.5 Sequential indicator lighting step setting [SEQ. IND. STEP]
⇒9.4.6 Sequential indicator lighting on/off setting [SEQ.IND.]
If the dimmer setting is [AUTO], the brightness of LEDs is decreased automatically
depending on the outside brightness. If the dimmer setting is [MANUAL], the brightness of
LEDs is decreased one level being interlocked with the illumination switch of the vehicle.
⇒9.3.5 Dimmer setting [DIMMER]
■Engine revolutions that LEDs start to light up
[SINGLE]＝(warning setting value of engine revolutions)－(lighting step)×8
[DUAL]＝(warning setting value of engine revolutions)－(lighting step)×4
■Engine revolutions that all LEDs light up
[SINGLE]＝[DUAL]＝(warning setting value of engine revolutions)－(lighting step)
■Engine revolutions that all LEDs blink
At higher than or equal to the warning setting value of engine revolutions
■Lighting example
warning setting value：8000RPM lighting step：100RPM
[SINGLE]
LEDs (from left) 1 2 3 4 5 6 7 8 Blink
Lighting revolutions(RPM) 7200 7300 7400 7500 7600 7700 7800 7900 8000
[DUAL]
LED (from left) 1 2 3 4 5 6 7 8 Blink
Lighting revolutions(RPM) 7600 7700 7800 7900 7900 7800 7700 7600 8000
※If ADVANCE BF Φ 80 Tachometer is connected, the higher setting value of warning would
be the basing point for lighting and blinking of LEDs.
