8.5. Setting and checking of operations
Both the switch unit of ADVANCE Control Unit and the buttons on the FD are used to set up
and operate.
1. Turn the ignition ON. Confirm DC SOURCE LED of ADVANCE Control unit lights up.
⇒Refer to manual of ADVANCE Control unit.
2. Confirm the opening mode is performed (and then the real time mode is displayed).
⇒9.6 Opening/Ending mode
3. Confirm short-circuit (SHORT) or disconnected (OPEN) errors are not displayed.
⇒9.9 Error display
If an error is displayed
→Turn the ignition off immediately, and then confirm the wiring of the sensor and the
sensor wire.
4. Set up the speed pulse, number of cylinders, and tachometer response in the system
setup mode.
⇒9.3 System setup mode
5. Set up the items displayed and warning values.
⇒9.4 Display setup mode
⇒9.8 Warning setup mode
6. Confirm the FD functions properly.
Warning
Set up while the vehicle is stopped.
