Defi ADVANCE FD User Manual

ADVANCE FD Manual 75 Return to top
10. Troubleshooting <for customer and installation personnel>
Warning
If any indication of the problem is found in the product, check to make sure the product
will operate as expected. Failure to do so can lead to serious accidents.
If any problem is found during using, setting or operating this product, use the following
table to confirm proper operation of the unit. If the operational problem is not found in the
following table, contact the installation personnel at the store where this product was
purchased.
Condition Possible Cause Corrective Action
○Wiring of the power supply
wire is improper.
○Check wiring of +B, IGN, GND as per
instructions in this manual.
○Connectors are plugged
into wrong positions.
○Check connectors' position.
○The fuse of the power
supply wire is blown out.
○Check wiring and replace the fuse.
○The locks of the solderless
connectors are not locked
tightly.
○Check the lock of the solderless
connectors.
○There is a wire short
circuit or disconnected wire
somewhere. Maybe there is
something wrong on gauge.
○Please reconfirm the wiring and the
gauge according to operation manual.
If any defects are not found, please ask
the shop for inspection.
○Does not carry out the
ending mode.
○The battery wiring is
improper.
○Check wiring of +B as per instructions
in this manual.
○Check the solderless connector of
battery wiring.
○Please ask the store for inspection.
○The illumination of
gauge does not turn on.
○The ILM wiring is improper.
○Check wiring of ILM as per instruc-
tions in this manual.
○The locks of the solderless
connectors are not locked
tightly.
○Check the lock of the solderless con-
nectors.
○The brightness level is set
at MANUAL LEVEL:0.
○Release illumination cancel function
as per instructions in this manual.
○The dimmer setting is
AUTO and the outside is
bright.
○Change the dimmer setting.
○Error (SHORT or OPEN)
is displayed.
○There is a wire short
circuit or a wire
disconnection somewhere on
sensor or sensor wire.
○Check the sensor and sensor wire as
per instructions in this manual. If any
defects are not found, please ask the
shop for inspection.
○Does not operate.
○Power is not supplied.
○DC Source LED of the
unit doesn't light.
