Displaying the LAG Configuration Table:
1 Open the LAG Configuration page.
2 Click Show All.
The LAG Configuration Table opens:
Figure 7-25. LAG Configuration Table
Configuring LAGs with CLI Commands
The following table summarizes the equivalent CLI commands for configuring LAGs as displayed in the
LAG Configuration page.
Table 7-13. LAG Configuration CLI Commands
CLI Command Description
interface port-channel
port-channel-number
Enters the interface configuration mode of a
specific port-channel.
port-channel load-
balance{
layer-2 |layer
2-3|layer 2-3-4
}
Configures the load balancing policy of the port
channeling.
description string
Adds a description to an interface
configuration.
shutdown
Disables interfaces that are part of the currently
set context.
speed bps
Configures the speed of a given ethernet
interface when not using auto negotiation.
