• If there is a mismatch in fan-out profile between master and the new member in stacking, the master
re-configures the member with its quad-mode profile, quad-mode, and stack-group configuration
and then reset the member. To avoid stack split during profile mismatch, the master does stack group
configurations of the new member.
To configure the quad-port-profile, use the following command:
CONFIGURATION mode
stack-unit [stack-unit number] quad-port-profile [default|list of ports]
The range of the stack-unit number is from 0 to 5. The defaults ports are:
2,4,6,8,9,10,11,12,13,14,15,16,17,18,19,20,21,22,23,24,25,27,29,31
Example:
stack-unit 0 quad-port-profile[default|list of ports]
To display the Fan-out capability profile, use the following show command:
show system stack-unit quad-port-profile
Example of the
show Command
The following example shows the system stack-unit quad-port-profile
command.
Dell(conf)#stack-unit 1 port 24 portmode quad
Warning: Enabling quad mode on stack-unit 1 port 24. Please
verify whether the configs related to interface Fo 1/24 are
cleaned up before proceeding further.
[confirm yes/no]:yes
Dell(conf)#00:02:24: %STKUNIT1-M:CP %IFMGR-5-DYNAMIC_FANOUT:
Port 24 in slot 1 has been fanned-out >>>>>
Dell(conf)#00:02:27: %S6000-ON:1 %IFAGT-5-INSERT_OPTICS_QSFP:
Optics QSFP inserted in slot 1 port 24/2
00:02:27: %S6000-ON:1 %IFAGT-5-INSERT_OPTICS_QSFP: Optics QSFP
inserted in slot 1 port 24/3
i00:02:27: %S6000-ON:1 %IFAGT-5-INSERT_OPTICS_QSFP: Optics
QSFP inserted in slot 1 port 24/4
Dell(conf)#stack-unit 1 port 24 portmode quad
Port 24 quad mode enabled
NOTE: Save and reload, after the setting takes effect.
FTOS(conf)#stack-unit 1 port 4 portmode quad
Port 4 quad mode enabled
Splitting QSFP Ports to SFP+ Ports
The platform supports splitting a single 40G QSFP port into four 10G SFP+ ports using one of the
supported breakout cables (for a list of supported cables, refer to the
Installation Guide or the Release
Notes).
NOTE: You can split the 40G ports to 10G ports and vice —versa without reloading the device.
To split a single 40G port into four 10G ports, use the following command.
