40G to 1G Breakout Cable Adaptor
As a default config command, you can see the speed CLI with options, 10M, 100M and, 1000M for all
front end interfaces. By default, the “show config” does not show the default speed. But if you change the
speed to 100 and comeback to speed 1000, it will show in “show config” or if you OIR 10G port with
speed 1000 with 40gto1g cable it will show you the default speed.
You can use speed command only to configure these on Mgmt-optic ports alone. Without any optic, if
you configure the speed, the configured will be assigned as the port speed to support Provisioning via
BMP.
User viewable Logs:
LOGS for optic insertion and removal are same as QSFP optics. You can use ‘'show inventory
media’
to check the optic type, or ‘'show interface transceiver'to know the optic properties.
show inventory media
0 88 QSFP 4x1000BASE-T US0XJYD04162059 Yes
0 89 QSFP 4x1000BASE-T US0XJYD04162059 Yes
0 90 QSFP 4x1000BASE-T US0XJYD04162059 Yes
0 91 QSFP 4x1000BASE-T US0XJYD04162059
Yes
show interface transceiver
QSFP 0 Serial ID Base Fields
QSFP 0 Id = 0x0d
QSFP 0 Ext Id = 0x00
QSFP 0 Connector = 0x0c
QSFP 0 Transceiver Code = 0x04 0x00 0x00 0x00 0x00 0x00 0x00 0x00
QSFP 0 Encoding = 0x05
QSFP 0 Length(SFM) Km = 0x00
QSFP 0 Length(OM3) 2m = 0x32
QSFP 0 Length(OM2) 1m = 0x00
QSFP 0 Length(OM1) 1m = 0x00
QSFP 0 Length(Copper) 1m = 0x00
QSFP 0 Vendor Rev = 0
Overview of Layer Modes
On all systems running Dell Networking OS, you can place physical interfaces, port channels, and VLANs
in Layer 2 mode or Layer 3 mode.
By default, VLANs are in Layer 2 mode.
Table 38. Layer Modes
Type of Interface Possible Modes Requires Creation Default State
10 Gigabit Ethernet and
40 Gigabit Ethernet
Layer 2
Layer 3
No Shutdown (disabled)
Management N/A No Shutdown (disabled)
Loopback Layer 3 Yes No shutdown (enabled)
Null interface N/A No Enabled
380
Interfaces
