SupportAssist

SupportAssist sends troubleshooting data securely to Dell. SupportAssist in this Dell Networking OS

release does not support automated email notification at the time of hardware fault alert, automatic case

creation, automatic part dispatch, or reports. SupportAssist requires Dell Networking OS 9.9(0.0) and

SmartScripts 9.7 or later to be installed on the Dell Networking device.

Figure 121. SupportAssist

SupportAssist

883
