ip route 192.168.0.22/32 10.11.0.23
!
ip pim rp-address 192.168.0.3 group-address 224.0.0.0/4
MSDP Sample Configurations
The following examples show the running-configurations described in this chapter.
For more information, see the illustrations in the Related Configuration Tasks section.
MSDP Sample Configuration: R1 Running-Config
MSDP Sample Configuration: R2 Running-Config
MSDP Sample Configuration: R3 Running-Config
MSDP Sample Configuration: R4 Running-Config
ip multicast-routing
!
interface TenGigabitEthernet 1/1/1
ip pim sparse-mode
ip address 10.11.3.1/24
no shutdown
!
interface TenGigabitEthernet 1/2/1
ip address 10.11.2.1/24
no shutdown
!
interface TenGigabitEthernet 1/21/1
ip pim sparse-mode
ip address 10.11.1.12/24
no shutdown
!
interface Loopback 0
ip pim sparse-mode
ip address 192.168.0.1/32
no shutdown
!
router ospf 1
network 10.11.2.0/24 area 0
network 10.11.1.0/24 area 0
network 192.168.0.1/32 area 0
network 10.11.3.0/24 area 0
!
ip multicast-msdp
ip msdp peer 192.168.0.3 connect-source Loopback 0
!
ip pim rp-address 192.168.0.1 group-address 224.0.0.0/4
ip multicast-routing
!
interface TenGigabitEthernet 2/1/1
ip pim sparse-mode
ip address 10.11.4.1/24
no shutdown
!
interface TenGigabitEthernet 2/11/1
ip pim sparse-mode
ip address 10.11.1.21/24
no shutdown
!
interface TenGigabitEthernet 2/31/1
ip pim sparse-mode
