TLV Sub-Type TLV Name TLV Variable System LLDP-MED MIB

Object

3 Location Identifier Location Data

Format

Local lldpXMedLocLocatio

nSubtype

Remote lldpXMedRemLocati

onSubtype

Location ID Data Local lldpXMedLocLocatio

nInfo

Remote lldpXMedRemLocati

onInfo

4 Extended Power via

MDI

Power Device Type Local lldpXMedLocXPoED

eviceType

Remote lldpXMedRemXPoED

eviceType

Power Source Local

lldpXMedLocXPoEPS

EPowerSource

lldpXMedLocXPoEP

DPowerSource

Remote

lldpXMedRemXPoEP

SEPowerSource

lldpXMedRemXPoEP

DPowerSource

Power Priority Local

lldpXMedLocXPoEP

DPowerPriority

lldpXMedLocXPoEPS

EPortPDPriority

Remote

lldpXMedRemXPoEP

SEPowerPriority

lldpXMedRemXPoEP

DPowerPriority

Power Value Local

lldpXMedLocXPoEPS

EPortPowerAv

lldpXMedLocXPoEP

DPowerReq

Remote

lldpXMedRemXPoEP

SEPowerAv

lldpXMedRemXPoEP

DPowerReq

548

Link Layer Discovery Protocol (LLDP)
