Chapter 8 Logic Instructions
8_
 Precautions for Correct Use

The input variables are not allowed to omit. An error will occur during the compiling of the software if
any input variable is omitted. But the output variable is allowed to omit.

The data type of output variables must be BOOL. Otherwise, an error will occur during the compiling
of the software.

Programming Example

The data types of GE_In1, GE_In2 and GE_In3 are INT, UINT and DINT respectively and the
data type of Out1 is BOOL.
Out1 changes to TRUE when the values of GE_In1, GE_In2 and GE_In3 are 100, 50 and 50
respectively and GE_EN changes to TRUE as shown in Variable 1.
Out1 changes to FALSE when the values of GE_In1, GE_In2 and GE_In3 are 10, 10 and 100
respectively and GE_EN changes to TRUE as shown in Variable 2.
 Variable 1
Variable name
Data type
Current value
GE_EN
BOOL
TRUE
GE_In1
INT
100
GE_In2
UINT
50
GE_In3
DINT
50
Out1
BOOL
TRUE
 Variable 2
Variable name
Data type
Current value
GE_EN
BOOL
TRUE
GE_In1
INT
10
GE_In2
UINT
10
GE_In3
DINT
100
Out1
BOOL
FALSE
 The program

The data types of GE_In1 and GE_In2 are both TIME and the data type of Out1 is BOOL.
Out1 changes to TRUE when the values of GE_In1 and GE_In2 are T#100ms and T#50ms
respectively and GE_EN changes to TRUE.
 The variable table and program
Variable name Data type Current value
GE_EN
BOOL
TRUE
GE_In1
TIME
T#100ms
GE_In2
TIME
T#50ms
Out1
BOOL
TRUE
1
GE
EN ENO
In1 Out
In3
In2
GE_EN
GE_In1
GE_In3
GE_In2
Out1
1
GE
EN ENO
In1 Out
In2
GE_EN
GE_In1
GE_In2
Out1
8-35
