 The table of Modbus device addresses
Device area
Device
type
Range Modbus address
Modbus address
type
I
（Input）
Bit
%IX0.0~%IX0.7
0x6000~0x6007
Standard Modbus
address
%IX1.0~%IX1.7
0x6008~0x600F
……
……
%IX127.0~%IX127.7
0x63F8~0x63FF
Word
%IW0~%IW63
0x8000~0x803F
Q
（Output）
Bit
%QX0.0~%QX0.7
0xA000~0xA007
%QX1.0~%QX1.7
0xA008~0xA00F
……
……
%QX127.0~%QX127.7
0xA3F8~0xA3FF
Word
%QW0~%QW63
0xA000~0xA03F
M
（Register）
Bit
%MX0.0~%MX0.7
0x10000000~0x10000007
Delta-extended
Modbus
addresses
%MX1.0~%MX1.7
0x10000008~0x1000000F
……
……
%MX131071.0~%MX131071.7
0x100FFFF8~0x100FFFFF
Word
%MW0~%MW32767 0x0000~0x7FFF
Standard Modbus
address
Word
%MW32768~%MW65535 0x20008000~0x2000FFFF
Delta-extended
Modbus addresses
3.1.2.3 Latched Devices
The %MW0~%MW999 devices are latched devices in which data are retained when power off. Besides, the
variables defined in the software can select Retain as its property. The capacity of latched devices is 128K
bytes.
