Chapter 12 Troubleshooting
1
1
11.3.20 DMC_WriteParameter_Motion
FB/FC Explanation Applicable model
FB
DMC_WriteParameter_Motion sets a slave parameter value. DVP15MC11T
Input Parameters
Parameter
name
Function Data type
Valid range
(Default)
Validation timing
Axis Specify the slave to control. USINT
1~127
(The variable
value must be
set)
When Execute
changes from
FALSE to TRUE
Execute
The instruction is executed
when Execute changes from
FALSE to TRUE.
BOOL
TRUE or
FALSE
(FALSE)
-
Index
The index of the parameter to
write.
UINT
SubIndex
The subindex of the parameter
to write.
USINT
DataType
The data type of the
parameter to write
1Byte,
2Word,
4Double Word.
USINT
Data
The value of the parameter to
write
UDINT
Notes:
1. DataType must be the data type of the parameter to write. An error will occur if the filled value is
incorrect.
2. Refer to Chapter 9 for the calculation of the index and subindex of servo parameters.
Output Parameters
Parameter name Function Data type Valid range
Done TRUE when the instruction execution is completed. BOOL TRUE / FALSE
Busy TRUE when the instruction is being executed. BOOL TRUE / FALSE
Active TRUE when the axis is being controlled. BOOL TRUE / FALSE
Error
TRUE when there is an error in the execution of the
instruction.
BOOL TRUE / FALSE
ErrorID
Contains the error code when an error occurs. Please
refer to section 12.2.
WORD
DMC_WriteParameter_Motion
Axis Done
DMC_WriteParameter_Motion_instance
Execute Busy
Active
Error
ErrorID
Index
SubIndex
DataType
Data
11-115
