DVP15MC11T Operation Manual
_8
8.15.3 ImmediateInput
FB/FC Explanation
Applicable
model
FC
ImmediateInput is used for the immediate refresh of input points. DVP15MC11T
ImmediateInput
EN ENO
Input
Num
 Parameters
Parameter name Meaning
Input/
Output
Description Valid range
Input Start input point Input Start input point 0~15
Num Number Input
Number of input points for
immediate refresh
1~16
Boolean
Bit string Integer
Real
number
Time, date
String
BOOL
BYTE
WORD
DWORD
LWORD
USINT
UINT
UDINT
ULINT
SINT
INT
DINT
LINT
REAL
LREAL
TIME
DATE
TOD
DT
STRING
Input
●
Num
●
Note:
The symbol ● indicates that the parameter is allowed to connect to the variable or constant of the data type.
 Function Explanation

The ImmediateInput instruction is used for refreshing external input point status to %IX0.0~%IX0.15.
If the ImmediateInput instruction does not exist, the controller refreshes external input point status
to %IX0.0~%IX0.15 once only every time the program scan starts.

The Input parameter value 0~15 corresponds to %IX0.0~%IX0.15. Num represents the quantity of
consecutive devices starting from the one specified by Input. E.g. when Input value is 0 and Num is
2, it indicates that the external input point status is refreshed to %IX0.0 and %IX0.1.
 Precautions for Correct Use

The instruction is only used for the immediate refresh of local input points instead of extension input
points.
8-210
