Chapter 8 Logic Instructions
8_
DVP-04AD is connected to the right side of DVP15MC11T. When TO2_Ex changes from FALSE to TRUE,
TO2_Bsy and TO2_Act change to TRUE simultaneously and the TO instruction execution starts. As
TO2_Done changes to TRUE, the instruction execution is completed and the values written in CR2, CR3,
CR4 and CR5 in DVP-04AD are the values written in the four elements TO2_DP[1], TO2_DP[2], TO2_DP[3]
and TO2_DP[4] of the TO2_DP array respectively.
