DVP15MC11T Operation Manual
12
1
 LAN1 LED
LAN1 LED indicates the network state of the first Ethernet communication port of the left side of
DVP15MC11T.
LED State Indication
Yellow
light
Blinking
Data are being sent or received via the first Ethernet port of
DVP15MC11T.
OFF
The first Ethernet port of DVP15MC11T is not connected to the
Ethernet network.
 LAN2 LED
LAN2 LED indicates the network state of the second Ethernet communication port of the left side of
DVP15MC11T.
LED State Indication
Yellow
light
ON
Data are being sent or received via the second Ethernet port of
DVP15MC11T.
OFF
The second Ethernet port of DVP15MC11T is not connected to the
Ethernet network.
 RS232 LED
RS232 LED, the RS-232 communication indicator of DVP15MC11T indicates the communication state
of RS-232 port of DVP15MC11T.
LED state Indication
Yellow light blinking There are response data via RS-232 port.
LED OFF There are no response data via RS-232 port.
 RS485 LED
RS485 LED, the RS-485 communication indicator of DVP15MC11T indicates the communication state
of RS-485 port of DVP15MC11T.
LED state Indication
Yellow light blinking There are response data via RS-485 port.
LED OFF There are no response data via RS-485 port.
 Input point LED
There are 16 input point LED indicators for showing if DVP15MC11T’s digital input points are ON or
OFF.
LED state Indication
Red light ON Input point is ON.
LED OFF Input point is OFF.
12-6
