Chapter 8 Logic Instructions
8_

If the value of InOutPos exceeds the range of the data type of InOut, the movement is not
performed.

If the value of Size exceeds the range, the movement is not performed.

Programming Example
 The variable table and program
Variable name
Data type
Current value
MovDigt_EN
BOOL
TRUE
MovDigt_In UDINT 16#1234
MovDigt_InPos UINT 1
MovDigt_InOutPos UINT 2
MovDigt_Size
UINT
2
MovDigt_Inout
UDINT
16#2300
 Move Figure
00101100
In=16#1234
Bit0
Bit3Bit4Bit7
01001000
Bit8Bit11Bit12Bit15
Digit 0
Digit 1
Digit 2Digit 3
00000000
Bit0Bit3Bit4Bit7
11000100
Bit8Bit11Bit12Bit15
Digit 0Digit 1Di git 2
Digit 3
......
...... ...... ......
..................
......
InPos=1
Size=2
InOutPos= 2
InOut=16#2300
1
MoveDigit
EN ENO
In
InPos
InOutPos
Size
InOut
MovDigt_EN
MovDigt_In
MovDigt_InOutPos
MovDigt_InPos
MovDigt_Size
MovDigt_InOut
8-23
