Delta AS Series Manual

AS Series Module Manual
Revision History
Version
Revision
Date
1
st
The first version was published.
2016 / 11/30
2
nd
1. Chapter 1: Added information concerning new models
AS08AD- B and AS08AD-C.
2. Chapter 2: Added information concerning new models
AS08AD- B andAS08AD-C.
3. Chapter 3: Updated information concerning CR#23- 24
and software new screenshots.
4. Chapter 4: Updated information concerning CR#35-
54/CR#210-225 and software new screenshots.
5. Chapter 5: Updated information concerning CR#1-
4/CR#210- 217 and s oftware new screenshots.
6. Chapter 6: Updated information concerning CR#210-
217 and s oftware new screenshots.
7. Chapter 7: Updated information concerning theoretical
calibration and s oftware new screenshots
8. Chapter 8: Updated information concerning new FW2.0.
2017 / 07/ 07
3
rd
1. Chapter 1: Added information concerning new models
AS06RTD- A and AS08TC- A and installation information
updated in section 1.3.1.
2. Chapter 5: Added information concerning new model
AS06RTD- A.
3. Chapter 6: Added information concerning new models
AS08TC- A.
2018/02/09
4
th
1. Chapter 1: Added information concerning ambient air
temperature- barometric pressure- altitude.
2. Chapter 2: Added information concerning filter average,
cable length and resistance. Updated section 2.2.4
CR#23-38 and section 2.2.5 CR#43- 74.
3. Chapter 3: Added information concerning cable length
and resistance. Updated section 3.2.1 ana
log to d igital
conversion range, o utput i mpedance and section 3.2.4
CR17- 20 and CR#21-36.
4. Chapter 4: Added information concerning filter average,
cable length and resistance. Updated section 4.2.1
analog to d igital c onversion r ange, o utput i mpedance
and 4.2.4 CR#31- 21.
5. Chapter 5: Updated section 5.2.1 JPt100 range, section
5.2.4- 5.2.5 added notes on CR, updated section 5.2.6
PID information, revised section 5.2.7 control mode.
6. Chapter 6: S ection 6.2.1 revised type B range, added a
note, section 6.2.4- 6.2.5 added notes on CR, revised
CR# for the records, updated section 6.2.6 PID
information and revised section 6.2.7 control m ode.
7. Chapter 7: S ection 7.2.4 added notes on CR.
8. Chapter 8: N ew functions in new FW2.02.
9. Chapter 9: U pdated section 9.2.5 o utput i mpedance
information and added sections 9.2.7.1- 9.2.7.9 for new
functions added and operational examples.
2018/11/26
5
th
1. Chapter 7: Revised contents of CR#0 and #59 in
section 7.2.4.
2. Chapter 8: Deleted a note in section 8.6.4.
2019/1/2 9
6
th
1. Chapter 5: Updated wiring information in section 5.2.8.
2019/5/10

Delta AS Series Specifications

General

Brand	Delta
Model	AS Series
Category	Control Unit
Language	English
