Delta AS Series Manual

AS Series Module Manual
7- 8
_7
CR# Name Description
Atr. Defaults
bit8: error in the power supply
bit9: error in the module hardware
bit10: error in calibration
bit11: error in CJC temperature
201
Instruction set
16#0101: record the peak value again for
channel 1
16#0102: record the peak value again for
channel 2
16#0104: record the peak value again for
channel 3
16#0108: record the peak value again for
channel 4
16#010F: record the peak values again for
channels 1–4
16#0201: enable recording for channel 1
16#0202: enable recording for channel 2
16#0204: enable recording for channel 3
16#0208: enable recording for channel 4
16#020F: enable recording for channels 1–4
16#0211: disable recording for channel 1
16#0212: disable recording for channel 2
16#0214: disable recording for channel 3
16#0218: disable recording for channel 4
16#021F: disable recording for channels 1–4
16#0502: restore default settings
W 0
210
The maximum peak
value for channel 1
Integer format; the maximum peak value for
analog inputs
R
-
211
The maximum peak
value for channel 2
-
212
The maximum peak
value for channel 3
-
213
The maximum peak
value for channel 4
-
214
The minimum peak
Integer format; the minimum peak value for
R -
