Delta AS Series Manual

Chapter 7 Temperature Measurement Module AS04/08TC
7- 7
7_
CR# Name Description
Atr. Defaults
8
Channel 4 offset
9
Channel 1 gain
Range: -32768 to +32767
R/W
1000
10
Channel 2 gain
R/W
11
Channel 3 gain
R/W
12
Channel 4 gain
R/W
13
Channel 1 average
times
Range: 1–100
R/W
10
14
Channel 2 average
times
15
Channel 3 average
times
16
Channel 4 average
times
17
Channel 1 filter average
percentage
Range: 0–3
Unit: ±10%
R/W
1
18
Channel 2 filter average
percentage
19
Channel 3 filter average
percentage
20
Channel 4 filter average
percentage
21
Units of temperature
0: Fahrenheit
1: Celsius
R/W 0
22
Channel alarm setup
0: open channel alarm
1: close channel alarm
bit0: channel 1
bit1: channel 2
bit2: channel 3
bit3: channel 4
0: warning
1: alarm
R/W 0
