Chapter 14 High Speed Counter Module AS02HC
14-5
14
Electrical specifications for the external outputs
Model
Item
AS02HC-A
Number of outputs
4
Connector type
D-sub15
Output type
NPN transistor (sinking)
Voltage / Current
5~30 VDC, 0.1 A
Maximum
load
Resistance
0.1 A
Inductance
-
Bulb
-
Maximum
output
frequency
Resistance
10 kHz
Inductance
-
Bulb
-
Maximum
Response
time
OFF→ON
25 us
Electrical isolation
500 VDC
Electrical specifications for the +5 V encoder power supply
Model
Item
AS02HC-A
Number of outputs
2 (+5VO/GND)
Connector type
D-sub15
Voltage / Current
5 VDC (±5%), 100 mA (Max)

Delta AS Series Specifications

General

Series	AS Series
Power Supply	24VDC
Cooling Method	Natural convection
Programming Language	Function Block Diagram (FBD)
Communication Interface	Ethernet, RS-232, RS-485
Output Voltage	24V DC
Output Current	2A
Operating Temperature	55°C
Storage Temperature	70°C
Protection Features	Overvoltage
Certifications	CE, UL
