ASDA-B2 Chapter 10 Specifications
Revision May, 2018
10-9
ECMA
F13 F18
08 13 18 08
Brake release time [ms (Max)]
10 10 10
10
Brake pull-in time [ms (Max)]
70 70 70
70
Vibration grade (um) 15
Operating temperature 0 ~ 40
o
C
Storage temperature -10 ~ 80
o
C
Operating humidity 20% to 90% RH (non-condensing)
Storage humidity 20% to 90% RH (non-condensing)
Vibration capacity 2.5 G
IP rating
IP65
(when waterproof connectors are used, or when an oil seal is
used to be fitted to the rotating shaft (an oil seal model is used))
Approvals
*3
Note:
*1. The rated torque is the continuous permissible torque between 0 ~ 40˚C operating
temperature which is suitable for the following heat sink dimension.
ECMA-__04 / 06 / 08: 250 mm x 250 mm x 6 mm
ECMA-__10: 300 mm x 300 mm x 12 mm
ECMA-__13: 400 mm x 400 mm x 20 mm
ECMA-__18: 550 mm x 550 mm x 30 mm
Material: Aluminum – F40, F60, F80, F100, F130, F180
*2. The built-in brake of the servo motor is for remaining the item in stop status. Do not use it to
decelerate or as the dynamic brake.
*3. The application of UL safety compliance for ECMA-F11308, ECMA-F11313, ECMA-F11318
is under processing.
*4. If desire to reach the max. torque limit of motor 250%, it is suggested to use the servo drive
with higher watt.
