Delta CMM-EIP02 - Online Monitoring Drive Parameters

VFD EtherNet/IP Option Card
Option Card Application Manual
35
4.3.2 Online Monitoring Drive Parameters
1. For communication setting method, see Section 4.3.1 <Network Parameter Setting for
Option Card>.
2. Go to Parameter List page to select the parameters that you need to monitor.
3. For example, if you need to monitor Pr.00-01, Pr.01-01, Pr.02-01, Pr.03-01, Pr.04-01,
Pr.05-01, and Pr.06-01, select these parameter number (Pr. No) in Parameter List page.
4. Then, the parameters that you selected to monitor display in Monitor page. Press Apply
button to finish the setting, and then DCISoft monitoring and cache functions automatically
open.
5. You can also enter Modbus address and length directly in Monitor page, and then
press Apply button to start monitoring.
