VFD EtherNet/IP Option Card
Option Card Application Manual
76
A.13 VFD Data Object (Class Code: 0x301)
A.13.1 Service Code
Service
Code
Implemented for
Service Name Description of Service
Class Instance
0x0E
Get_Attribute_Single
Read attribute content of the
specified object
0x10
Set_Attribute_Single Modify attribute value
A.13.2 Instance Code: 0x01
Attribute = Parameter Modbus Address (Decimal) + 1
Instance & Attributes
Modbus Address Attributes
Access
Rule
Name Data Type
Description of
Attribute
0x0000–0x0E63 1–3684
Get / Set*
VFD Parameter. UDINT, STRING
VFD parameter
data
0x2000–0x2002 8193–8195 Get / Set VFD Command UDINT, STRING
VFD command
Data
0x2100–0x211F 8449–8480 Get VFD Status UDINT, STRING VFD status Data
0x2200–0x2231 8705–8754 Get VFD Status UDINT, STRING VFD status Data
0x2600–0x2601
0x2660–0x2662
9729–9730
9825–9827
Get VFD Command UDINT, STRING
VFD command
Data
0x2640–0x2641
0x26A0–0x26A2
9793–9794
9889–9891
Get / Set VFD Command UDINT, STRING
VFD command
Data
0x6000–0x6007 24577–24584 Get / Set VFD Command UDINT, STRING
VFD command
Data
0x6100–0x6106 24833–24839 Get VFD Status UDINT, STRING VFD status Data
*NOTE: See the user manual of the drive to check if the parameters are read-only. It they are read-only, it
is suggested not change the attribute value.
