Delta CMM-EIP02 User Manual

VFD EtherNet/IP Option Card
Option Card Application Manual
75
A.12 VFD Data Object (Class Code: 0x300)
A.12.1 Service Code
Service
Code
Implemented for
Service Name Description of Service
Class Instance
0x0E

Get_Attribute_Single
Read attribute content of the
specified object
0x10

Set_Attribute_Single Modify attribute value
A.12.2 Instance Attributes
Instance & Attributes
Instance Attributes
Access
Rule
Name Data Type Description of Attribute
0x00–0x0E 0x00–0x63
Get / Set*
VFD Parameter UDINT, STRING
VFD parameter data
Instance: Parameter Group
Attribute: Parameter Number
0x20 0x00–0x02 Get / Set VFD Command UDINT, STRING VFD command Data
0x21 0x00–0x1F Get VFD Status UDINT, STRING VFD status Data
0x22 0x00–0x31 Get VFD Status UDINT, STRING VFD status Data
0x26
0x00–0x01
0x60–0x62
Get VFD Command UDINT, STRING VFD command Data
0x40–0x41
0xA0–0xA2
Get / Set VFD Command UDINT, STRING VFD command Data
0x60 0x00–0x07 Get / Set VFD Command UDINT, STRING VFD command Data
0x61 0x00–0x06 Get VFD Status UDINT, STRING VFD status Data
*NOTE: See the user manual of the drive to check if the parameters are read-only. It they are read-only, it
is suggested not change the attribute value.
