Delta CMM-EIP02 User Manual

VFD EtherNet/IP Option Card
Option Card Application Manual
66
A.2 Supported Object
Object Name
Class
Code
Description
Supported
Models
Identity Object 0x01
Describes device information, including manufacturer,
device type and version.
All models
Message Router Object 0x02
Provides connection status and supported number of
connections.
All models
Assembly Object 0x04
Aggregates data for input and output data associated
with I/O connections
All models
Connection Manager Object 0x06 Establishes CIP connection All models
Device Level Ring Object 0x47
Enables with DLR function setting and connection
status
Two-port
option card
QoS Object 0x48
Distinguishes priorities by packet. When device support
DLR function, DLR packet has priority over normal
packet (in consideration of system recovering time).
Two-port
option card
TCP/IP Interface Object 0xF5 Displays IP setting method and IP setting interface All models
Ethernet Link Object 0xF6
Displays connection status for each Ethernet port on
the device.
All models
VFD Data Object 0x300 Reads/writes drive’s data object All models
VFD Data Object 0x301 Reads/writes drive’s data object All models
A.3 Supported Data Type
Data Type Description
BYTE 8-bit string
WORD 16-bit string
DWORD 32-bit string
STRING[n] String consists of n characters
SHORT_STRING String consists of characters
USINT 8-bit unsigned integers
UINT 16-bit unsigned integers
UDINT 32-bit unsigned integers
