Delta CMM-EIP02 User Manual

VFD EtherNet/IP Option Card
Option Card Application Manual
73
A.10 TCP / IP Interface Object (Class Code: 0xF5)
A.10.1 Service Code
Service
Code
Implemented for
Service Name Description of Service
Class Instance
0x01

Get_Attribute_All
Read attribute content of multiple
objects
0x0E
 
Get Attribute Single
Read attribute content of the
specified object
0x10

Set Attribute Single Modify attribute value
A.10.2 Instance Code: 0x00
Class
Attribute ID
Access
Rule
Name Data Type Description of Attribute
0x01 Get Revision UINT Object version 4
A.10.3 Instance Code: 0x01
Instance
Attribute ID
Access
Rule
Name Data Type Description of Attribute
0x01 Get Status DWORD Interface status
0x02 Get Configuration Capability DWORD Interface capability flags
0x03 Get / Set Configuration Control DWORD Interface control flags
0x04 Get
Physical Link STRUCT
Path Size UINT 0x0002
Path Padded EPATH [20] [F6] [24] [01]
0x05 Get / Set
Interface Configuration STRUCT
IP Address UDINT 192.168.1.5
Network Mask UDINT 255.255.255.0
Gateway Address UDINT 192.168.1.1
Name Server UDINT Primary name server
Name Server 2 UDINT Secondary name server
Domain Name STRING Default domain name
0x06 Get / Set Host Name STRING Host name
