Delta CMM-EIP02 User Manual

VFD EtherNet/IP Option Card
Option Card Application Manual
72
A.9 Qos Object (Class Code: 0x48)
A.9.1 Service Code
Service
Code
Implemented for
Service Name Description of Service
Class Instance
0x0E
 
Get_Attribute_Single
Read attribute content of specified
object
0x10

Set_Attribute_Single Modify attribute value
A.9.2 Instance Code: 0x00
Class
Attribute ID
Access
Rule
Name Data Type Description of Attribute
0x01 Get Revision UINT Object version 1
A.9.3 Instance Code: 0x01
Instance
Attribute ID
Access
Rule
Name Data Type Description of Attribute
0x01 Get/Set 802.1Q Tag Enable USINT
Enable 802.1Q packet transmission
0: disable (Default); 1: enable
0x04 Get/Set DSCP Urgent USINT
0x05 Get/Set DSCP Scheduled USINT
0x06 Get/Set DSCP High USINT
0x07 Get/Set DSCP Low USINT
0x08 Get/Set DSCP Explicit USINT
