VFD EtherNet/IP Option Card
Option Card Application Manual
6
1. Introduction to EtherNet/IP
EtherNet/IP is
a communication protocol used in industrial automation, and can be applied for
control, security, synchronization, motion control, configuration and information. This industrial
Ethernet communication protocol is managed by the ODVA Association (Open DeviceNet Vendors
Association). The name "IP" stands for "Industrial Protocol". EtherNet/IP is based on TCP/IP
communication protocol so it can easily work with generally-used IT networks and provides high-
speed and stable applications for Factory Automation (FA), Building Automation (BA), and Program
Automation (PA). Delta's EtherNet/IP products cover a wide range of control and drive products,
such as Programmable Logic Controllers (PLC), Variable Frequency Drive (VFD), Human-Machine
Interface (HMI), thermostats (DTM), switches (Ethernet Switch), and so on. It can also be connected
with other brand EtherNet/IP devices through EDS files. For correct communication, use Delta's
products as your first choice for PLC.
Option cards that support EtherNet/IP for M300 and C2000 drive series are CMM-EIP02/03 and
CMC-EIP01/02. You can also use DCISoft software to remotely set and monitor through the Internet,
or remotely monitor by using CMM-EIP02 that works with drawing control software or HMIs. If you
use devices that support auto MDI / MDI-X detection function, you do not need to use crossover
cables.
2. Communication Specification
Item
Specification
CMM-EIP02
CMC-EIP01
CMM-EIP03
CMC-EIP02
Communication Protocol ICMP, IP, DHCP, BOOTP, EtherNet/IP Adapter, Modbus TCP
Transmission Speed 10/100 Mbps Auto-Detection
Communication Mode IEEE 802.3, IEEE 802.3u
Cable Category 5e shielding 100 M
Communication Interface RJ45 with Auto MDI/MDIX
Ethernet Port Number 1 2
Modbus TCP
Type of Device Server
Topology Star, Linear bus Star, Linear bus
Support Function Code Depending on the drive’s Modbus specification
Maximum Number of Connections 16 (differentiated from EtherNet/IP)
Maximum Data Length for Single
Connection
100 Words
EtherNet/IP
Type of Device Adapter
Maximum Number of Connections
8 (differentiated from Modbus TCP, all EIP types are
calculated altogether)
Topology Star, Linear bus (two ends)
Star, Linear Bus, Ring (DLR
Ring Node)
EtherNet/IP
Implicit Messaging
(I/O Connection)
Requested packet interval (RPI) 5–1000 ms
Packets per second 400 pps
EtherNet/IP
Explicit Messaging
Type
Class 3 (Connected Type)
UCMM (Unconnected Type)
Supported Objec
t See Appendix A <EtherNet/IP Service and Object> for details
