Chapter 7 Memory Card
b. When the source for back up is from ISP Project:
(6)
The CPU module still performs the data backup even if you click Cancel. You can turn off the CPU
module to stop the data backup; however, the backup file produced is not a complete backup file, and you
must delete the backup file from the memory card.
If you select Memory Card (PLC Side), the filename of the backup file is AUTOEXEC.dup, and the
backup file path is Root directory of the memory card\ES3\SysDup\AUTOEXEC.dup. If there is an old
backup file in the memory card, the Warning message appears. Click Replace, Archive, or Cancel in the
Warning message.
If the backed up data is protected by passwords, these passwords are also backed up.
Data backup Description
CPU module Memory card
The backed up data includes the PLC ID and the PLC password set
in the CPU module.
ISPSoft project Computer
The backed up data includes the program ID and the project
password set in the ISPSoft project.
To Next Page
