Delta DVP-ES3 Series

Chapter 9 Ethernet Specification and Operation
9-65
9_
 When Instance = 1, the Instance Attributes are listed below.
Instance
Attribute
Name
Access
Rule
Data
Type
Values Description
H’00 M0 Get/Set BOOL H’00 M0 bit register
H’01 M1 Get/Set BOOL H’00 M1 bit register
H’02-H’1FFE M2-M8190 Get/Set BOOL H’00 M2-M8190 bit register
H’1FFF M8191 Get/Set BOOL H’00 M8191 bit register
9.8.14 S Register (Class ID: 354 Hex)
 Service Code
Service Code Service Name
Support
Description
Class Attribute
Instance
Attribute
H’0E Get_Attribute_Single X V Read one attribute
H’10 Set_Attribute_Single X V Write one attribute
H’32 Read_Parameter X V Read Parameter
H’33 Write_Parameter X V Write Parameter
 Class
 Class ID：H’354
 Instance
 H’01：Instance Attribute, Bit Register
 When Instance = 1, the Instance Attributes are listed below.
Instance
Attribute
Name
Access
Rule
Data
Type
Values Description
H’00 S0 Get/Set BOOL H’00 S0 bit register
H’01 S1 Get/Set BOOL H’00 S1 bit register
H’02-H’7FE S2-S2046 Get/Set BOOL H’00 S2-S2046 bit register
H’7FF S2047 Get/Set BOOL H’00 S2047 bit register
