Chapter 7 Memory Card
7.7 Restoring a Project
If the restoration source or restoration destination is a CPU module or memory card, make sure that ISPSoft is
connected to the CPU module. During restoration, the CPU LED and Error LED blinks alternatively and SM452
flag is ON. After restoration is done, the CPU LED and Error LED stops blinking and SM452 flag is OFF. For
ISPoft operation, refer to Section 2.4 in the ISPSoft User Manual or for DIADesigner, refer to Chapter 5 in the
DIADesigner User Manual for more information.
The following operation demonstration is for ISPSoft.
(1)
Select
Restore (From DUP File)
in the
CARD Utility
wizard and then click
Next
.
(2)
Select a restoration source, click and then select a backup file to be restored.
a. If you select
Memory Card (PLC side) (Need Connection)
, the backup files in the memory card
display in a window after you click . Double-click a backup file in the window to choose it.
To Next Page
