Delta DVP-ES3 Series Hardware Manual

DVP-ES3/EX3/SV3/SX3 Series Hardware and Operation Manual
1-14
_1
DVP02TKL-S
2 generic analog inputs: 0~10V, 0~20 mA, 4~20 mA
Thermocouple: J, K, R, S, T, E, N, B, C, L, U, TXK (L), PLII
Thermistor: Pt100, JPt100, Pt1000, Cu50, Cu100, Ni100,
Ni120, Ni1000, LG-Ni1000
Resolution: 0.1°C (16-bit)
2 analog outputs: 0~10V, 0~20 mA, 4~20 mA
Resolution: 12-bit
Output points: controlled by PID or manual
Positioning
module
DVP01PU-S Single axis positioning module; 200k Hz
Left-side
positioning
module
DVP02PU-SL
2-axis motion control
5-24 VDC, 1 differential input (A/B/Z phase), maximum
hardware input frequency at 200k Hz, 24 VDC, 5 mA, 5
inputs, maximum hardware input frequency at 1 kHz,
5 VDC, 2-axis (4 points) differential outputs, maximum
output frequency at 200k Hz
Left-side
high-speed
communication
module
DVPEN01-SL Ethernet module; 10/100Mbps
DVPDNET-SL DeviceNet Master module; 500k bps
DVPCOPM-SL CANopen Master module; 1Mbps
DVPPF02-SL PROFIBUS DP Slave module; 12Mbps
DVPSCM12-SL RS-485/RS-422 series communication module; 460k bps
DVPSCM52-SL
BACnet MS/TP Slave module; 460k bps
