Chapter 10 CANopen Function and Operation

10-7

 Non-synchronous mode





    

PLCScancycle PLCScancycle PLCScancycle PLCScancycle PLCScancycle

Explanation:

: After PLC scan time ends, PLC CPU refreshes to update the task of sending PDO.

: If the data in PDO changes, PLC CPU sends PDO.

: The data in PDO remains the same, the PDO here is NOT sent.

Note: You can use the function of setting up the PLC scan time to ensure PLC CPU checks the task of

sending PDO in every set scan time.
